smartCAP

Pick-by-Light button with daisy chain connection

The smartCAP button uses its 6 cm pick display with 7-segment code and LEDs to signal how many items are to be picked from which position. The picking process is confirmed by the integrated touch button - ergonomically without effort.

Pick-by-Light button surface mounting

smartCAP SMC46 with printed symbol and SMC47 with 7-segment display

Pick-by-Light button profile mounting

smartCAP SMC46 with printed symbol and SMC47 with 7-segment display

Impressive features

smartCAP buttons are impact-resistant, vandal-proof and have a long service life of several 100 million switching cycles. They are also 100 percent water- and oil-tight. Thanks to their extreme robustness, downtimes and maintenance requirements can be reduced enormously.

Capacitive button
High operating comfort, even with gloves. No pressure required.
Over 100 million switching cycles
Very robust against shock and vibration, 100% waterproof and dustproof (IP69K / Nema 6P)
Excellent visibility
Bright LED ring with different colors + 7-segment display
Ergonomic design
60mm touch surface for easy and quick activation
100% Uptime
Condition monitoring & preventive maintenance of functionality and operation
4 storage locations with one button
Segmentation of the LED ring allows addressing up to 4 storage positions with one button

Picking safely and without errors

Quantity correction

The "long press" function of the smartCAP buttons can be used for quantity correction or for refilling the storage room. Thanks to RGB technology, up to seven employees can work in a picking zone at the same time. This greatly increases working speed and productivity.

Freely configurable functions

The color displays of the LEDs can be individually adapted to your needs: up to 16 million color variants are possible in total. Other parameters such as the minimum actuation time, the dynamic response of the actuation and the interface behavior can also be individually adjusted.

Product views

Front view SMC46 Surface mounting

Front view SMC46 Surface mounting

Rear view SMC46+47 Surface mounting

Rear view SMC46+47 Surface mounting

Front view SMC47 profile mounting

Front view SMC47 profile mounting

Rear view SMC46+47 profile mounting

Rear view SMC46+47 profile mounting

Technical drawings - profile mounting

All dimensions in mm

Front view SMC47

Front view SMC47

Front view SMC46

Front view SMC46

Rear view

Rear view

Side view

Side view

Technical drawings - surface mounting

All dimensions in mm

Front view SMC47

Front view SMC47

Front view SMC46

Front view SMC46

Rear view

Rear view

Side view

Technical data

at 24V DC and 20°C

Supply voltage
DC 24 V (16,8 ... 32 V)
Latency time
Approx. 70 ms
LED colors
RGB LED´s (7 colors programmable)
Reverse polarity protection
Protection of all lines
Short-circuit protection
Short-circuit and overload protection
Power consumption
0,5 W
Operating temperature
-10 ...+50 °C / 14…122°F
Storage temperature
-20°C...+60°C / -4…140°F
Degree of protection
Frontside IP69K
Type of operation
Capacitive
Operation force
No operation force required
